Cutting Chain Replacement On A Chainsaw

by HIPA Jeremy 25 Nov 2022 0 Comments


This blog is a step-by-step instruction on how to replace a cutting chain on chainsaws. The most common reason for replacing the cutting chain is when the chainsaw does not cut properly.

Replacement

Before you replace the cutting chain on your chainsaw, you need to first make sure the chainsaw’s engine has cooled.
Step 1: Release the top cover clips and lift the cover off.
Step 2: Remove the wire and boot from the spark plug to prevent the chainsaw from accidentally starting.
Step 3: Now remove the nuts securing the clutch cover and pull the cover off.
Step 4: Remove the chain bar and pull off the old chain.
Step 5: Install the new chain by aligning it on the chain bar. You need to make sure the teeth on the chain are facing towards the front end of the chain bar on the top and away from the front end on the bottom.
Step 6: Loop the chain onto the clutch sprockets as you align the chain bar on the mounting bolts.
Step 7: Put the cover back on. And the chain tensioner will need to be inserted into the hole in the chain bar. You probably need to rotate the tension adjustment screw counterclockwise to properly align the tensioner.
Step 8: With the cover in place, hand tighten the nuts. Now lift the bar and rotate the adjustment screw clockwise until there is no slack in the chain. Fully tighten the nuts and confirm that the chain is taut.
Step 9: Attach the wire and boot to the spark plug. Realign the top cover and secure it with the clips.

HIPA SAW CHAINS

Click Here and Find the Saw Chain You Need

Please let us know if this works and if you have any suggestions or comments. Or you can join HIPA DIY COMMUNITY to feature your passion for repair projects, share your stories with the Hipa family and get help from Hipa.
